Product Details:
|
| Use: | Truck Trailer | Type: | Semi-Trailer |
|---|---|---|---|
| Material: | Steel, Steel | Size: | 13600x2600x4000mm (customizable), 13600x2600x4000mm (customizable) |
| Max Payload: | >30000 Kg | Product Name: | Open Wing Catgo Van Semi Trailer |
| Function: | Like LOGISTIC CARGO TRANSPOTATION | Color: | Customer's Request |
| Axle: | 13T 16T BPW/FUWA | King Pin: | 90#(3.5") JOST/Other Brand |
| Main Bean: | Q345B/T700 | Rim: | 9.00-22.5 |
| Tire: | 12R22.5 12units |
Product Name | Wosheng Wind Van Semi Trailer |
Color | According to customer demands. |
Tare weight | 8.5tons |
Tire | 12R22.5 12units (brand optional) |
Loading capacity | 30-40tons |
Axle | WS/BPW/FUWA ,13T 16T, American/ German axle |
Main beam | Q345B Steel upper plate is 14mm middle plate is 8mm down plate is 16mm |
Side beam | 3mm |
Open manner | side door and the left wing can be expanded or customized |
Axle | WS/BPW/FUWA ,13T 16T, American/ German axle |
Base Plate | 3mm |
King pin | 50#(2")/90#(3.5") JOST/Other Brand |
Tire | 12R22.5 12units (brand optional) |
Suspension | Mechanical/Air suspension system |
Brake System | Dual line brake system, Air chamber T30/30, 3 X 40L gas storage drums |
Light | LED |
Landing Gear | 28 Ton JOST/Other Brand |
Rim | 9.00-22.5 |
ABS | None or installed as your requirement. |
Electrical system | 1. Voltage: 24v waterproof 2. Receptacle: 7 ways (7 wire harness); LED light (standard rear light, turn light, rear reflector, side light, side reflector etc.) |
Accessories | 1. A toolbox |
2. with a set of standard trailer tools |
