40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain

40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain

Large Image :  40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain

Product Details:
Place of Origin: Shandong China
Brand Name: WOSHENG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $15,200.00/units 1-4 units
Payment Terms: T/T, L/C
Contact Now

40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 13900*2500*4000mm (customizable)
Max Payload: 40tons Product Name: Curtain Side Van Semi Trailer
Axle: 13T 16T BPW/FUWA Color: Customer's Request
Suspension System: Mechanical /Air Suspension Brake System: Dual Line Brake System WABCO
Suspension: Mechanical Suspension Air Suspension Tire: 11.00r20 12r22.5 315 385
King Pin: 50(2")/#90(3.5") Leaf Spring: 90(W)mm*13/16 (Thickness)mm*10(Layer)
Brake: WABCO-ABS

40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 0
Products picture
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 1
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 2
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 3
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 4
Products Description
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 5
Trailer Model
Curtain Slider Semi Trailer
Overall Dimension (Lx W x H)(mm)
13900*2500*4000 (customizable)
Tare Weight(KG)
7000
Loading Weight( KG)
40000
Total Weight(KG)
50000
Axle Brand
13Ton Axle FuWa Brand
Axle Number
Three
Wheelbase(mm)
7450+1310+1310
Suspension system
Mechanical Suspension
Steel Spring
10/10/10 leaf spring suspension
The material of Main beam
The height of the beam is 500mm,
upper plate is14mm,
down plate is 16mm,
middle plate is 8mm.
Side Beam
18mm
Platform plate
3mm Diamond plate
Curtain Height
2000mm
Slider
Manual operation
Tire Type and quantity
11.00r20 12r22.5 315 385 13units brand optional
Traction Pin
50(2")/#90(3.5")
Spare Wheel Bracket
1 pieces
Tool Box
1 Standard
Landing Gear
28ton
Brake system
Dual Line braking system, WEBCO valve, with ABS
Brake air chamber
Six big chamber
Electrical system
1. Voltage: 24v
2. Receptacle: 7 ways (7 wire harness)
Side Guard
Tail lamp with turn signal, brake light & reflector, side lamp etc.One set 6-core standard Cable. Accept customization.
Painting
Color as customer’s requirement
Packing
Unpacked, Polish with wax before shipping
Delivery way
Transfer to Qingdao,Tianjin or Lianyungang Port, and carry by ro-ro ship or bulk ship, the freight cost depends on the volume.
Products detail
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 6
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 7
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 8

Axle suspension and brake system

BPW Fuwa worldwide best axles worki with WABCO brake valve, More effectively brake for safe and save tire cost
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 9

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 10

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 11

Tire

use famous brand , or according to customer

40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 12
Company Profile
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 13
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 14
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 15
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD. Our company focuses on the development and production of semi-trailer, engaged in the semi-trailer industry has more than 20 years of rich experience, is a real set of trade and production as one of the manufacturers.our experienced staff can discuss your requirements at any time to ensure your full satisfaction. modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 16
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 17
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 18
Certification
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 19
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 20
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 21
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 22
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 23
We are your most reliable cooperation partner.
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 24
Packing and Shipping
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 25
Exhibition
40tons Max Payload Tri-axle Enclosed Cargo Box Semi Trailer with Customizable Side Curtain 26
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
