40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload

40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload

Large Image :  40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload

Product Details:
Place of Origin: Shandong, China
Brand Name: wosheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $15,500.00/sets 1-4 sets
Payment Terms: T/T, L/C
Contact Now

40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload

Description
Use: Truck Trailer Type: Semi-Trailer, Side Curtain Semi Trailer
Material: Steel, Q345B T700 Size: 13750x2550x4000
Max Payload: >40000 Kg Axles: 2/3/4 Axles
Tare Weight: 7T Color: Customized Color
Painting: Customization Payload: Customization
Tire Specification: 12R22.5 Customized Rim: 9.0-22.5
Lead Time: 10 Days

Products Description
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 0
Side Curtain Semi trailer
*** Speaking of side curtain trailers, since both side and rear doors can be opened, the brake operation width can reach the entire lenth of the carriage, saving 70% of the loading and unloading time
*** Light Weight : the curtain fabric of the side curtain car is lighter than the composite plate of the ordinary box car, and it is equipped with high-strength light weight materials to improve the loading and unloading weight of the goods
*** Good protection of the side curtain , in additional to improving the loading and unloading and sealing efficiency, but also in the transportation process of dust and rain , to protect special goods from pollution
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 1
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 2
Specification
Detail Specification
Items
Side curtain semi trailer
Tare Weight
7.0Tons (depends on final configuration)
Payload
40 tons or cutomizable
Size
13900x2500x4000mm (customization)
Inside Size
13280X2440X2547mm （customization)
Main Beam
Q345B/T700 steel
Height 500mm
Upper Plate is 14mm
Down plate is 16mm
Middle plate is 8mm or customization
Bottom Plate
Thickness 3mm (customization)
Curtain Height
2000mm
Slider
Manual Operation
Axles
13/16/20 tons, axle amount optional like 2/3/4 axles etc, axle brand optional like SAF, FUWA, BPW etc
King pin
2.00"(50#), bolting king pin, JOST  or another brand according to customer
Suspension
Mechanical suspension air suspension (American or Geman)
Leaf Spring
10pcs leaf spring, thickness 13mm. width 90mm
Tire specs
12R22.5/315 80R22.5/11R20/12R20 Choose freely
 Braking system
dual line brake system , Air chamber T30/30 3X40L gas storage drums
Rim
9.00-22.5 /8.00-20/8.5-20
ABS system
None or installed as your requirement.
Painting
Sanding , anti-corrosion , one primer paining add two layer top coat painting
Side Gurd
According to customer
Electrical system
24 volt electrical system 7 pin electrical connector, Parking stop, reverse, number plate and indicator lights, rear lights conform to european  standard, rear front and side reflectors
spare tire
Two set of heavy duty spare wheel carriers, indluding a riser
Tool Box
One Piece (1.0 x 5.0 m) with 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar
Color
According to customers requirements
Delivery
From China Port and carry by container ship, ro-ro ship or by bulk
Remark
Our senior engineer can design semi trailer as your request, and we accept OEM/ODM projects
Drawing
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 3
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 4

Suspention - Anti-Tire Abrasion

Specially designed anti-Tire abrasion suspension system prevent tire deflection after loading and avoids tires to the maximum extent worn out. and easy to disassemble and maintain
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 5

bottom

stronger sturction
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 6

Axle suspension and brake system

BPW Fuwa worldwide best axles worki with WABCO brake valve, More effectively brake for safe and save tire cost , Fix quality springs and suspension , support longer service life, save maintain cost
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 7

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 8

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 9

Tire

use famous brand , or according to customer

Company Profile
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 10
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD.
Our Company mainly produce fence semi trailer, lowbed semi trailer , low fence semi trailer , rear dump semi trailer, container flat semi trailer, fuel oil semi trailer, etc all kinds of semi trailer, Our company have more than 20 years produce and exporting experience Quality is firstly, Credit is our base for business, Welcome to know us and build business relationship.
Recommend Products
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 11
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 12
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 13
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 14
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 15
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 16
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 17
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 18
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 19
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 20
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 21
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 22
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 23
Factory :
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in
appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 24
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 25
Packing and Loading
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 26
Container usually us 45 feet
Usually by bulk
Certification
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 27
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 28

we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 29
40 45 53 Ft Van Box Sliding PVC Tarpaulin Side Curtain Semi Trailer 40 Ton Payload 30
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
High quality , factory lower price , good service !
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
