30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction

30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction

Large Image :  30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction

Product Details:
Place of Origin: Shandong, China
Brand Name: WOSHENG side dump semi trailer
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $8,300.00/sets 1-9 sets
Payment Terms: T/T, L/C
Contact Now

30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction

Description
Use: Truck Trailer, Truck Triler Type: Semi-Trailer
Material: Steel, Steel Size: 13000*2550*2900mm (customizable), 13000*2550*2900mm (customizable)
Max Payload: >30000 Kg Product Name: Wosheng Side Dump Semi Trailer
Color: Customer's Request Axle: 13T 16T BPW/FUWA
King Pin: 2"(50mm)or3.5"(90mm) Suspension: Mechanical Suspension
Leaf Spring: 90(w)mm*13/16(thickness)mm*10Layer Rim: 9.00*22.5/8.00-20/8.5-20

Products Description
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 0
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 1
Max Load 30-100 Ton Steel and Carbon Steel Side Dump Truck Semi Trailer Box Type for Coal and Sand Transport
Wosheng Dump Semi Trailers are in great demand from customers, the proven product, which features reliable structure , great loading capacity, excellent power, reliable performance. This trailer model could meet the requirements of different road conditions, and could satisfy your need of long distance highway transportation
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 2
Specification
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 3
Loading Capacity
30-100 ton
Landing Gear
China brand standard 28Tons
Receptacle
7 ways (7 wire harness)
Tool box
One piece 1m *0.5m*0.5m ( size can be customized)
Manufacturer
Shandong Wosheng Special Vehicle Manufacturing Co.,Ltd
Type
Side Dump semi trailer
Semi trailer Dimension
13000*2550*2900mm(can be customized)
Inside dimension
12800mm*2350mm600mm （can be customized)
Side wall height
600mm
Side wall thicknes(mm)
1.5mm - 2.5mm Q235 steel
Door
Vertical corrugated, 2mm thickness zinc-iron alloy bending parts.
Door frame
50*70*2 high strength pipe
Tare weight
8.5 tons
Bottom plate thickness(mm)
2mm zinc-rion alloy plate or 3mm plain plate
Lifting system
130 Hydraulic Lifting Cylinder
Main beam
Q345B Steel
Height: 500mm
upper plate is 14mm
middle plate is 8mm
down plate is 16mm
Axle
13T/16T,FUWA/BPW/ WS etc
Spring leaf
90(w)mm*13/16(thickness)mm*10Layer
King pin
90# or 50#
Landing Gear
China brand standard 28Tons
Suspension
Mechanical suspension
Rim
9.00-22.5/8.00-20/8.5-20
Tire
12.00R22.5/315 80R22.5/11.00R20/12.00R20 Various tire brands are available
Braking system
WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber, 45L air tank
Tool box
One piece 1m *0.5m*0.5m (accept customized size)
Spare wheel carrier
1 set
Painting
1. Sand blasting processing clean rust 2.coat of anticorrosive prime, 3 coats of final paint 4.colors optional
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 4

Axle

BPW/FUWA/LEAO Axle optional.Integrated advanced low-alloy axle beam,Whole axle beam no welding process.strong carrying capacity and high bending strength.Axle maintenance-free could reach 3 year/400,000 kilometers.
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 5

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C.
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 6

Suspension and break system

Suspension: Germany Type or American Type Mechanical and Air bag suspension can be choose.
Brake System: T30/30 Spring brakechamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 7

Tire

Double Coin / Ling Long / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance.
Company Profile
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 8

About us

Qingdao Wosheng Import and Export Co., Ltd., is a company engaged in semi-trailer, truck, used semi-trailer, used-truck, auto parts and new energy vehicles’ sales and service. Our factory is Shandong Wosheng Special vehicle manufacturing co.,ltd , which has nearly 8 years of production experience in the trailer industry. Please believe that our professional technology and manufacturing experience can help your transportation be safer and efficient. we can provide high quality products and competitive prices.
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 9
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 10
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 11
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 12
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 13
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 14
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 15
Factory
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 16
Certifications
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 17
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 18
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 19
Packing and Loading
30-100 Ton Side Dump Semi Trailer for Coal and Sand Transport Heavy Duty Construction 20
FAQ
Q1. Are you a factory or trade company ?
We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time. Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc. Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion. Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality. Q5. What services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF Q6. What logistics ways we can work for shipment? We can ship all trailer by various transportation tools. For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania etc, either by container or RoRo/Bulk Shipment. For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
