12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport

12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport

Large Image :  12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport

Product Details:
Place of Origin: Shandong China
Brand Name: Wo Sheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7,600.00/units 1-3 units
Payment Terms: T/T, L/C
Contact Now

12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12500x2500x1600-3100mm Or Customizable
Max Payload: >30000 Kg Function: Transport 20ft 40ft Container
Main Beam: Q345B, Height 0.5m, Upper /down/middle Plate Is 14/16/8mm Color: Customized Color
Leaf Spring: 90(w)mm*13/16(thickness)mm*10(layer) King Pin: 2"(50mm)or3.5"(90mm)
Axle: 13ton*3 Axles Suspension: Mechanical Suspension
Landing Gear: 28t Heavy Duty Landing Gear Tire: 12.00R22.5
Tools Box: 1 Standard

Products Description
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 0
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 1
Flatbed Semi Trailer
Flatbed semi-trailers are usually used to transport 20FT/40FT container The lower the center of gravity, the better the stability and safety, the better the ability to transport super high loads and pass overhead obstacles.
According to the number of axles and the size of the tires, the load of the flatbed semi trailer is also different. The more the number of axles, the greater the load, and the load range is between 30-80 tons.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 2
Specification
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 3
Products name
Flatbed Semi Trailer
Max payload
＞30 TON
Size
12500x2500x1600-3100mm or customizable
Main Beam
Q345B Height 500mm upper plate is 14mm,
down plate is 16mm,
middle plate is 8mm.
Side Beam
Q235 16# channel steel
Leaf Spring
90(w)mm*13/16(thickness)mm*10(layer)
Landing Gear
28t Heavy Duty Landing Gear
Electrical System
1. Voltage: 24v waterproof 2. Receptacle: 7 ways (7 wire harness)
King Pin
2"(50mm)or3.5"(90mm)
Axle
13Ton, 3 axles
Suspension
Mechanical Suspension
Tire
12.00R22.5(Brand optional)
Rim
9.00-22.5
Bottom Platform
3mm diamond plate
Accessory
One tooling box with a set of standard trailer tool.
Painting
Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosion prime,2 coats of final paint
Packaging and delivery
by sea transfer to Qingdao or Lianyungang Port, and carry by ro-ro ship or bulk cargo ship, the freight cost depends on the
volume.
Remarks
We can design model according to client's requirement
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 4
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 5
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 6

Axle

BPW/FUWA/LEAO Axle optional.Integrated advanced low-alloy axle beam,Whole axle beam no welding process.strong carrying capacity and high bending strength.Axle maintenance-free could reach 3 year/400,000 kilometers.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 7

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 8

Leaf Spring

Usually 10pcs leaf spring , 13mm thickness, 90mm width.
Can customizable according to customer requirements.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 9

Twist Lock

ISO standard twist locks are durable with unique design, which ensures the stability of containers and ease of loading and unloading.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 10

Suspension and break system

Suspension: Germany Type or American Type Mechanical and Air bag suspension can be choose. Brake System: T30/30 Spring brakechamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 11

Tire

Double Coin / Ling Long / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance.
Company Profile
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 12

About us

Qingdao Wosheng Import and Export Co., Ltd., is a company engaged in semi-trailer, truck, used semi-trailer, used-truck, auto parts and new energy vehicles’ sales and service. Our factory is Shandong Wosheng Special vehicle manufacturing co.,ltd , which has nearly 8 years of production experience in the trailer industry. Please believe that our professional technology and manufacturing experience can help your transportation be safer and efficient. we can provide high quality products and competitive prices.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 13
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 14
Factory
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 15
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 16
Certifications
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 17
We have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 18
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 19
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 20
Packing and Loading
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 21
12.00R22.5 Tire 60 Tons 80 Tons Payload Flatbed Semi Trailer for Container Transport 22
FAQ
Q1. Are you a factory or trade company ?
We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time. Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc. Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion. Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality. Q5. What services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF Q6. What logistics ways we can work for shipment? We can ship all trailer by various transportation tools. For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania etc, either by container or RoRo/Bulk Shipment. For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
