Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel

Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel

Large Image :  Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel

Product Details:
Place of Origin: SHANDONG CHINA
Brand Name: WOSHENG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $10,150.00/units 1-4 units
Payment Terms: T/T, L/C
Contact Now

Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel, Steel Size: 9800x2500x3500mm(CUSTOMIZABLE), 9800x2500x3500mm(CUSTOMIZABLE)
Max Payload: >30000 Kg Main Beam: Q345B
Color: Customer's Request Leaf Spring: 90(w)mm*13/16(thickness)mm*10(layer)
King Pin: 2"(50mm)or3.5"(90mm) Axle: 13/16/20 Ton.
Suspension: Mechanical Suspension Tire: 12.00R22.5/315 80R22.5/11.00R20/12.00R20

Products Description
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 0
New Design 3-6 Axles Hydraulic Rear Dump Truck Trailer 30-100 ton U Type Rear Dump Semi Trailer For Sale
Wosheng Dump Semi Trailers are in great demand from customers, the proven product, which features reliable structure , great loading capacity, excellent power, reliable performance. This trailer model could meet the requirements of different road conditions, and could satisfy your need of long distance highway transportation.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 1
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 2
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 3
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 4
Specification
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 5
Wosheng Rear Dump Tipper Semi Trailer
Application
Transport all kinds of Mineral/Coal/Stone/Sand/Cargo Loading
Model
2 axles tipper trailer
3 axles tipper trailer
4 axles tipper trailer
5 - 6 axles tipper trailer
Bucket capacity
25 cubic meters
30/35/40 cubic meters
40 cubic meters
45 cubic meters
Dimension （mm）
8500*2500*3500
10000x2500x3800
10500*2500*3900
11500*2500*3950
Rim and tires
12.00R22.5 tires
9.0-22.5 rims
12.00R22.5 tires
9.0-22.5 rims
315/80R22.5 tires
9.0-22.5 rims
12.00R20 tires
9.0-20


Lifting system
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=202 mm
HYVA brand
FE/FC type cylinders
Diameter=214 mm
Tipping box
T700 / Hardox


Main Beams
T700 / Q345B double plate
Height:500mm
Upper Plate: 14mm
Middle Plate: 8mm
Lower Plate: 16mm
Axle
13T/16T FUWA / BPW / LEAO Own Brand
King Pin
JOST brand 2.0'' / 3.5'' bolt type king pin
Landing Gear
28T double speed JOST / TAIHUA brand
Suspension
Heavy duty mechanical suspension / Air bag / Bogies
Pneumatic Braking System
WABCO RE 6 relay valve
T30/30 air brake chamber
Spring leaf
90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
(special for export market )
Light
LED light,24V,7ways(7 wire harness)

Tool Box
steel/aluminum

One piece,1m*0.5m*0.5m(Size can be choose freely)
Painting
1 coat of anticorrosive prime, 2coats of final paint
Any parts fitted could according to clients request, contact us to get more.
Details Images
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 6
Reinforcement side plate supporting design
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 7
Brake system
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 8
Tool box with enough important emergency tools
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 9
Spare Tire
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 10
Front axle lifting
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 11
Libricate counteraxle
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 12

Hydraulic and Power takeoff box, No need to install power output device on the engine


Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 13

Tail light guard


Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 14
Hydraulic dust cover
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 15
Double Coin / LingLong / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 16

Anti-Tire abrasion Suspension

Specially designed anti-Tire abrasion suspension system,Prevent tire offset after loading, maximally avoid tire
abrasion.Meanwhile,Easy to disassemble and maintain.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 17

Axle :BPW/FUWA/LEAO Axle optional.

Integrated Advanced Low-Alloy Axle Beam,Whole
Axle Beam No Welding process.Strong Carrying
Capacity and high bending Strength.Axle
maintenance-free could reach 3 Year/400,000
kilometers.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 18
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 19
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 20
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 21
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 22
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 23
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 24
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 25
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 26
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 27
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 28
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 29
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 30
Company Profile
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 31
About us
Qingdao Wosheng Import and Export Co., Ltd., is a company engaged in semi-trailer, truck, used semi-trailer, used-truck, auto parts and new energy vehicles’ sales and service. Our factory is Shandong Wosheng Special vehicle manufacturing co.,ltd , which has nearly 8 years of production experience in the trailer industry. Please believe that our professional technology and manufacturing experience can help your transportation be safer and efficient. we can provide high quality products and competitive prices.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 32
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 33
Factory
Our factory commit to strict quality
control and thoughtful customer
service, our experienced staff can
discuss your requirements at any time
to ensure your full satisfaction. We
not only want to be perfect in
appearance, but also pursue the
delicacy of detail. We have advanced
modern equipment, strong technical
force to ensure customer satisfaction
of products and timely delivery.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 34
Certifications
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 35
We have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 36
Why Choose Us
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 37
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility
model patents. We have attracted customers from all over the world, whether choosing the current
product from our catalog or seeking technical support for your application, you can talk to our
customer service colleagues about your procurement needs.
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 38
Packing and Loading
Design 30-100 ton U Type Rear Dump Semi Trailer with Max Payload 30000 kg and Steel 39
FAQ
Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.
Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements.
Such as: special Size, special control, or OEM/ODM etc.
Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.
Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF

Q6. What logistics ways we can work for shipment?
We can ship all trailer by various transportation tools
For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania etc, either by container or RoRo/Bulk Shipment.
For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
