3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm

3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm

Large Image :  3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm

Product Details:
Place of Origin: Shandong, China
Brand Name: Yun Sheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $8,000.00/sets 1-3 sets
Payment Terms: T/T, L/C
Contact Now

3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel/stainless Steel Size: 9300x2500x3450mm
Max Payload: >60000 Kg Axle: 3/4 Pcs Or Customization
Suspension: Mechanical Or Air Suspension Landing Gear: 28T
Color: Customization Supply Ability: 15000 Sets Per Year
Lead Time: 15 Days Brake System: Air Drum Brake
Rim: 9.0*22.5 / 8.0-20 / 8.5-20 King Pin: 2"(50mm)or3.5"(90mm) JOST
Condition: New

Products Description
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 0
Hydraulic Rear Dump Semi Trailer
Wosheng Dump Semi Trailers are in great demand from customers, the proven product, which features reliable structure , great loading capacity, excellent power, reliable performance. This trailer model could meet the requirements of different road conditions, and could satisfy your need of long distance highway transportation.
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 1
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 2
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 3
Specification
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 4
Wosheng Rear Dump Tipper Semi Trailer
Application
Transport all kinds of Mineral/Coal/Stone/Sand/Cargo Loading
Model
2 axles tipper trailer
3 axles tipper trailer
4 axles tipper trailer
5 - 6 axles tipper trailer
Bucket capacity
25 cubic meters
30/35/40 cubic meters
40 cubic meters
45 cubic meters
Dimension （mm）
8500*2500*3500
10000x2500x3800
10500*2500*3900
11500*2500*3950
Rim and tires
12.00R22.5 tires
9.0-22.5 rims
12.00R22.5 tires
9.0-22.5 rims
315/80R22.5 tires
9.0-22.5 rims
12.00R20 tires
9.0-20


Lifting system
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=202 mm
HYVA brand
FE/FC type cylinders
Diameter=214 mm
Tipping box
T700 / Hardox


Main Beams
T700 / Q345B double plate
Height:500mm
Upper Plate: 14mm
Middle Plate: 8mm
Lower Plate: 16mm
Axle
13T/16T FUWA / BPW / LEAO Own Brand
King Pin
JOST brand 2.0'' / 3.5'' bolt type king pin
Landing Gear
28T double speed JOST / TAIHUA brand
Suspension
Heavy duty mechanical suspension / Air bag / Bogies
Pneumatic Braking System
WABCO RE 6 relay valve
T30/30 air brake chamber
Spring leaf
90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
(special for export market )
Light
LED light,24V,7ways(7 wire harness)

Tool Box
steel/aluminum

One piece,1m*0.5m*0.5m(Size can be choose freely)
Painting
1 coat of anticorrosive prime, 2coats of final paint
Any parts fitted could according to clients request, contact us to get more.
Details Images
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 5
Reinforcement side plate supporting design
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 6
Brake system
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 7
Tool box with enough important emergency tools
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 8
Spare Tire
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 9
Front axle lifting
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 10
Libricate counteraxle
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 11

Hydraulic and Power takeoff box, No need to install power output device on the engine


3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 12

Tail light guard


3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 13
Hydraulic dust cover
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 14
Double Coin / LingLong / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 15

Anti-Tire abrasion Suspension

Specially designed anti-Tire abrasion suspension system,Prevent tire offset after loading, maximally avoid tire
abrasion.Meanwhile,Easy to disassemble and maintain.
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 16

Axle :BPW/FUWA/LEAO Axle optional.

Integrated Advanced Low-Alloy Axle Beam,Whole
Axle Beam No Welding process.Strong Carrying
Capacity and high bending Strength.Axle
maintenance-free could reach 3 Year/400,000
kilometers.

Recommend products
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 17
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 18
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 19
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 20
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 21
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 22
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 23
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 24
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 25
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 26
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 27
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 28
Company Profile
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 29
About us
Qingdao Wosheng Import and Export Co., Ltd., is a company engaged in semi-trailer, truck, used
semi-trailer, used-truck, auto parts and new energy vehicles’ sales and service. Our factory is
Shandong Wosheng Special vehicle manufacturing co.,ltd , which has nearly 8 years of production
experience in the trailer industry. Please believe that our professional technology and manufacturing
experience can help your transportation be safer and efficient. we can provide high quality products
and competitive prices.
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 30
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 31
Factory
Our factory commit to strict quality
control and thoughtful customer
service, our experienced staff can
discuss your requirements at any time
to ensure your full satisfaction. We
not only want to be perfect in
appearance, but also pursue the
delicacy of detail. We have advanced
modern equipment, strong technical
force to ensure customer satisfaction
of products and timely delivery.
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 32
Certifications
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 33
we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000
Quality Management Certification. We are also a national high-tech enterprise and have obtained
more than 30 invention patents and utility model patents.
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 34
Why Choose Us
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 35
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility
model patents. We have attracted customers from all over the world, whether choosing the current
product from our catalog or seeking technical support for your application, you can talk to our
customer service colleagues about your procurement needs.
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 36
Packing and Loading
3-Axle 4-Axle 5-Axle Tilting Tipping Tipper Rear Dump Truck Trailer 9300x2500x3450mm 37
FAQ
Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research
and development, production and sales. Welcome to visit our factory at any time.
Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional
engineers will design and our well-trained staff will produce according to customer special requirements.
Such as: special Size, special control, or OEM/ODM etc.
Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process,
finished products. Advanced equipment and standard inspection process ensure the quality.
Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF

Q6. What logistics ways we can work for shipment?
We can ship all trailer by various transportation tools
For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East,
Africa, Oceania etc, either by container or RoRo/Bulk Shipment.
For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can
ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international
courier service, such as DHL, TNT, UPS, or Fedex.
