40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable

40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable

Large Image :  40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable

Product Details:
Place of Origin: Shandong, China
Brand Name: Yun Sheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $8,000.00/sets 1-4 sets
Payment Terms: T/T, L/C
Contact Now

40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12400x2610x1550mm Or Customization
Max Payload: >40000 Kg Color: Customization
Usage: Container Etc All Kind Of Cargo Axle: 3 Axles Or Customization
Tare Weight: 7.0 Ton Or Customaization Loading Capacity: 50 Tons Or Customization
King Pin: 2.00" (50#)/(90#) Tire Specs.: 12R22.5, Triangle Brand Or According Customer Reauirements
Rim: 9.0-22.5 Main Beam: Q345b/ T700
Lead Time: One Week

Products Description
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 0
Flat bed semi trailer
Features: Flatbed plate semi -trailer is a kind of semi-trailer without wall and canopy, with simple structure and stong adaptability,
Application scenario: It is mainly used to transport various goods with unlimited length,width and height. such as construction materials, steel products and heavy machinery
Technological development: In recent years , with the application of light weight and strength materials , the loading capacity of plate semi trailer has been greatly improved
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 1
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 2
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 3
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 4
Drawing
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 5
Specification
Detail Specification for flatbed semi trailer
Items
Flat bed semi tailer
Tare Weight
7.0 Tons
Payload
50Tons
Size
12400x2610x1550mm
Frame
Main Beam: Opting for high strength Q345B steel, 520mm deep welded I-section main beams, Top flange thickness 14mm, Bottom flange
thickness 16mm, Middle flage thickness 8mm
Cross Beam: Heavy duty thickened 10# channel steel
Side Beam: Heavy duty 18# channel steel
Floor: 3mm thickness checkered plate
Axles
13/16/20 tons, axle amount optional like 2/3/4/5/6 axle ... axle brand optional like SAF/FHWA/BPW etc
King pin
2.00"(50#), bolting king pin, JOST brand
Suspension
Heavy duty type tri-axles suspension with equalizers. American design
Steel Spring
Six sets of reliable famous brand , 10pcs leaf spring, thickness 13mm. width 90mm
Landing gear
28tons lifting capacity , two speed
Tire specs
12R22.5 Triangle brand , or another brand according to customer
Rim
9.00-22.5 brand according to customer
Paiting
Sanding , anti-corrosion , one primer paining add two layer top coat painting
Side Gurd
According to customer
Electrical system
One unit of 24v 7-pin ISO 1185 socket: LED light
spare tire
Two set of heavy duty spare wheel carriers, indluding a riser
Tool Box
One Piece (1.0 x 5.0 m) with 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 6

Suspention - Anti-Tire Abrasion

Specially designed anti-Tire abrasion suspension system prevent tire deflection after loading and avoids tires to the maximum extent worn out. and easy to disassemble and maintain
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 7

Twist Lock

ISO standard lock suitable worldwide container,additional protection switch avoid mistake opperate
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 8

Axle suspension and brake system

BPW Fuwa worldwide best axles worki with WABCO brake valve, More effectively brake for safe and save tire cost , Fix quality springs and suspension , support longer service life, save maintain cost
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 9

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 10

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 11

Chassis Frame

It is mainly used to enhance the load-bearing capacity and overall rigidity of the vehicle body, ensure the stability and durability of the vehicle when transporting heavy-loaded items
Recommend Products
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 12
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 13
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 14
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 15
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 16
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 17
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 18
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 19
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 20
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 21
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 22
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 23
Company Profile
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 24
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD.
Our Company mainly produce fence semi trailer, lowbed semi trailer , low fence semi trailer , rear dump semi trailer, container flat semi trailer, fuel oil semi trailer, etc all kinds of semi trailer, Our company have more than 20 years produce and exporting experience Quality is firstly, Credit is our base for business, Welcome to know us and build business relationship.
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 25
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 26
Factory :
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in
appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 27
Packing and Loading
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 28
Container usually us 45 feet
Usually by bulk
Certification
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 29

we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 30
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 31
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
High quality , factory lower price , good service !
40-120 Tons Payload Flatbed Semi Trailer for Container and All Kind of Cargo Suitable 32
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
