Product Details:
Place of Origin: Shandong China
Brand Name: Wo Sheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7,600.00/units 1-3 units
Payment Terms: T/T, L/C

Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12500x2500x1600-3100mm Or Customizable
Max Payload: 50tons Function: Transport 20ft 40ft Container
Main Beam: Q345B, Height 0.5m, Upper /down/middle Plate Is 14/16/8mm Color: Customized Color
Leaf Spring: 90(w)mm*13/16(thickness)mm*10(layer) King Pin: 2"(50mm)or3.5"(90mm)
Axle: 13ton*3 Axles Suspension: Mechanical Suspension
Landing Gear: 28t Heavy Duty Landing Gear Tire: 12.00R22.5

Products Description
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 0
Flatbed Semi Trailer
Flatbed semi-trailers are usually used to transport 20FT/40FT container The lower the center of gravity, the better the stability and safety, the better the ability to transport super high loads and pass overhead obstacles.
According to the number of axles and the size of the tires, the load of the flatbed semi trailer is also different. The more the number of axles, the greater the load, and the load range is between 30-80 tons.
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 1
Specification
Products name
Flatbed Semi Trailer
Max payload
40-100TON
Size
12500x2500x1600-3100mm or customizable
Main Beam
Q345B Height 500mm upper plate is 14mm,
down plate is 16mm,
middle plate is 8mm.
Side Beam
Q235 16# channel steel
Leaf Spring
90(w)mm*13/16(thickness)mm*10(layer)
Landing Gear
28t Heavy Duty Landing Gear
Electrical System
1. Voltage: 24v waterproof   2. Receptacle: 7 ways (7 wire harness)
King Pin
2"(50mm)or3.5"(90mm)
Axle
13Ton, 3 axles
Suspension
Mechanical Suspension
Tire
12.00R22.5(Brand optional)
Rim
9.00-22.5
Bottom Platform
3mm diamond plate
Accessory
One tooling box with a set of standard trailer tool.
Painting
Complete Chassis sand blasting to clean rust, 1 coat of anti-corrosion prime,2 coats of final paint
Packaging and delivery
By sea transfer to Qingdao or Lianyungang Port, and carry by ro-ro ship or bulk cargo ship, the freight cost depends on the volume.
Remarks
We can design model according to client's requirement
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 2

Axle

BPW/FUWA/LEAO Axle optional.Integrated advanced low-alloy axle beam,Whole axle beam no welding process.strong carrying capacity and high bending strength.Axle maintenance-free could reach 3 year/400,000 kilometers.
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 3

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C.
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 4

Leaf Spring

Usually 10pcs leaf spring , 13mm thickness, 90mm width.
Can customizable according to customer requirements.
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 5

Twist Lock

ISO standard twist locks are durable with unique design, which ensures the stability of containers and ease of loading and unloading.
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 6

Suspension and break system

Suspension: Germany Type or American Type Mechanical and Air bag suspension can be choose.
Brake System: T30/30 Spring brakechamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.
Transport 20ft 40ft Containers with WS Container Twist Lock 50ft or 53 ft Flatbed Trailers 7

Tire

Double Coin / Ling Long / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance.
