Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer

Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer

Large Image :  Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer

Product Details:
Place of Origin: Shandong, China
Brand Name: Yun Cheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7,000.00/sets 1-4 sets
Payment Terms: T/T, L/C
Contact Now

Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12.38x2.48x1.55m
Max Payload: >30000 Kg Color: Customized Color
Tare Weight: 6.5 Tons Usage: Container Transport
King Pin: 2.00 Or 3.5 Inch Bolt In King Pin Landing Gear: 28ton/pc
Main Beam: Q345B Rim: 9.0-20*12pcs 90#
Tire: 12R22.5*12pcs Lead Time: 7 Days
Condition: New

Products Description
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 0
Container skeleton trailer
Wosheng 2 axle 3Axle 20ft 40ft Skeleton Gooseneck Container Chassis trailer
***When using a container chassis trailer to transfer the goods, it can be directly loaded in the consignor's warehouse and transported to the consignee's warehouse for unloading. When changing vehicles and ships midway, there is no need to remove the cargo from the container and reload it.
*** It can be quickly loaded and unloaded, and can be directly and conveniently converted from one mode of transportation to another.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 1

1.The skeleton is the main product of our company, fully digesting and absorbing the characteristics of similar products at home and abroad, with strong loading capacity and high reliability.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 2

2.The frame chassis of this series adopts the through-beam structure, and the frame structure includes straight and gooseneck types. The overall strength is high, the weight is light, the appearance is beautiful, and the use is safe and reliable.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 3

3.Using advanced manufacturing technology, submerged arc automatic welding is used for longitudinal beams, and shot blasting is performed on the whole frame to effectively eliminate welding residues.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 4

4.In the spraying process, advanced spraying powder and baking technology are used to ensure that the vehicle is not easy to rust and beautiful.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 5

5.Wosheng's raw materials ensure the quality of the products, and the procurement, inspection and use are strictly in accordance with the requirements of the quality system, which ensures the good performance of the vehicle.
Drawing
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 6
Wosheng Skeleton Container Trailer
20FT Skeleton Semi Trailer
40FT Skeleton Semi Trailer
45FT Skeleton Semi Trailer
Brand: Wosheng
Brand: Wosheng
Brand: Wosheng
2 Axles/3 Axles
3 Axles/ 4 Axles
3 Axles/ 4 Axles
20ft Container Loading
1*40ft/2*20ft Container Loading
1*45ft/1*40ft/2*20ft Container Loading
Loading Capacity: 20-50 Tons
Loading Capacity: 30-80 Tons
Loading Capacity: 30-80 Tons
Type: Gooseneck or Tandem
Type: Gooseneck or Tandem
Type: Gooseneck or Tandem
Main Bean
Material: Q345/T700
Material: Q345/T700
Material: T700
Upper Plate Thickness: 12mm
Upper Plate Thickness: 14mm
Upper Plate Thickness: 10mm
Middle Plate Thickness: 6mm
Middle Plate Thickness: 6mm
Middle Plate Thickness: 5mm
Lower Plate Thickness: 12mm
Lower Plate Thickness: 16mm
Lower Plate Thickness: 10mm
Height: 500mm
Height: 500mm
Height: 420mm
Dimension
L*W*H: 7000mm*2480mm*1560mm
L*W*H: 12400mm*2480mm*1580mm
L*W*H: 13950mm*2500mm*1600mm
Axle
2/3 Axles *13 Ton
Wosheng/FUWA/BPW or Anothers
3/4 Axles *13 Ton
Wosheng/FUWA/BPW or Anothers
3/4 Axles *13/16 Ton
Wosheng/FUWA/BPW or Anothers
Tire
12R22.5 (8/12 Pieces)
Linglong/Triangle/Double
Coin/Bridgestone
12R22.5 (12/16 Pieces)
Linglong/Triangle/Double
Coin/Bridgestone
12R22.5 (12/16 Pieces)
Linglong/Triangle/Double
Coin/Bridgestone
Rim
9.00*22.5 (8/12 Pieces)
Steel/Aluminum
9.0*22.5 (12/16 Pieces)
Steel/Aluminum
9.00*22.5 (12/16 Pieces)
Steel/Aluminum
Leaf Spring
90mm*13mm*10 Pieces
90mm*16mm*10 Pieces
90mm*13mm*10 Pieces
90mm*16mm*10 Pieces
90mm*13mm*10 Pieces
90mm*16mm*10 Pieces
King Pin
#50 (2")/#90 (3.5")
JOST/Other Brand
#50 (2")/#90 (3.5")
JOST/Other Brand
#50 (2")/#90 (3.5")
JOST/Other Brand
Landing Gear
28 Tons Two Speed
JOST/Other Brand
28 Tons Two Speed
JOST/Other Brand
28 Tons Two Speed
JOST/Other Brand
Twist Lock
4 Sets
12 Sets
12 Sets
Painting
Electrophoresis Painting
Electrophoresis Painting
Electrophoresis
Specification
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 7
Wosheng Moisture-proof LED lights:

Equipped with LED moisture-proof lamps to prevent short circuits and ensure the safety of vehicles transportation at night.
Landing Gear:
The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premlum chassis oil and is rated for service from -30°C to 120°C.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 8
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 9
Axle:
WPW/FUWA/Wosheng Axle Optional. Integrated Advanced Low-Alloy Axle Beam,Whole Axle Beam No Welding process.Strong Carrying Capacity
and high bending Strength.Axle maintenance-free could reach 3 Year/400,000 kilometers
Twist Lock:
The twist locks are durable with unique design, which ensures the stability of containers and ease of loading and unloading.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 10
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 11
Suspension and break system:
Suspension: Germany Type or America Type Mechanical and Air bag suspension can be choose.
Specially designed anti-Tire abrasion suspension system, prevent tire offset after loading, maximally avoid tire abrasion.
Meanwhile, Easy to disassemble and maintain.
Brake system: T30/30 Spring brake chamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.

Recommend Products
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 12
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 13
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 14
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 15
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 16
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 17
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 18
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 19
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 20
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 21
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 22
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 23
Company Profile
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 24
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD.
Our Company mainly produce fence semi trailer, lowbed semi trailer , low fence semi trailer , rear dump semi trailer, container flat semi trailer, fuel oil semi trailer, etc all kinds of semi trailer, Our company have more than 20 years produce and exporting experience Quality is firstly, Credit is our base for business, Welcome to know us and build business relationship.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 25
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 26
Factory :
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in
appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 27
Packing and Loading
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 28
Container usually us 45 feet
Usually by bulk
Certification
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 29

we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 30
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 31
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
High quality , factory lower price , good service !
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 32
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
Design 2 Axle 3 Axle 40 Tons Truck Trailer for Port Transfer Steel Skeleton Semi Trailer 33
