120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment

120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment

Large Image :  120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment

Product Details:
Place of Origin: Shandong, China
Brand Name: WS
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $10,635.00/sets 1-4 sets
Payment Terms: T/T, L/C
Contact Now

120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment

Description
Use: Truck Trailer Type: Semi-Trailer, Lowbed Semi Trailer
Material: Steel, Q345B Size: 13000x3000x1700mm
Max Payload: >60000 Kg Axles: 2/3/4/5 Axles
Tare Weight: 9.5 T Color: Customized Color
Painting: Customization Payload: 120 T
Tire Specification: 12R22.5 Customized Rim: 9.0-22.5
Lead Time: 10 Days

Products Description
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 0
Lowbed semi trailer
Lowbed semi trailer have plate types, concave beam type and exposed tire type structure, its frame for the ladder, longitudinal beam section for the i-shape, with high stiffness, high strength characteristics.
The main plane of the frame and cargo platform is low, which ensures the smoothness of transportation.
Specification
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 1
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 2
Detail Specification
Items
lowbed semi trailer
Tare Weight
9.5 Tons
Payload
60 Tons
Size
13000x3000x3300mm or customization
Main Beam
Q345B / T700 steel upper late is 16mm down plate is 18mm , middle plate is 12mm (customization)
Side Beam
20# channel steel (customization)
Bottom plate
4mm diamond steel (customizable
Wheelbase
8580+1310+1310mm
Axles
3 axles, square axle with 13 tons capacity FUWA brand , or 2 4 5 axle can be choose
King pin
2.00"(50#), bolting king pin, JOST brand
Suspension
Heavy duty type tri-axles suspension with equalizers. American design
Steel Spring
Six sets of reliable famous brand , 10pcs leaf spring, thickness 13mm. width 90mm
Landing gear
28tons lifting capacity
Twist Lock
4/8/12 units (customization)
Tire specs
12R22.5 Triangle brand , or another brand according to customer
Rim
9.00-22.5 brand according to customer
Brake System
dual line brake system, air chamber T30/30 3X40l gas storage drums
ABS System
None or installed as your requirement
Paiting
Sanding , anti-corrosion , one primer paining add two layer top coat painting
Side Gurd
According to customer
Electrical system
One unit of 24v 7-pin ISO 1185 socket: LED light
spare tire
Two set of heavy duty spare wheel carriers, indluding a riser
Tool Box
One Piece (1.0 x 5.0 m) with 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar
Drawing
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 3
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 4

Suspention - Anti-Tire Abrasion

Specially designed anti-Tire abrasion suspension system prevent tire deflection after loading and avoids tires to the maximum extent worn out. and easy to disassemble and maintain
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 5

Twist Lock

ISO standard lock suitable worldwide container,additional protection switch avoid mistake opperate
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 6

Axle suspension and brake system

BPW Fuwa worldwide best axles worki with WABCO brake valve, More effectively brake for safe and save tire cost , Fix quality springs and suspension , support longer service life, save maintain cost
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 7

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 8

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 9

Chassis Frame

It is mainly used to enhance the load-bearing capacity and overall rigidity of the vehicle body, ensure the stability and durability of the vehicle when transporting heavy-loaded items
Recommend Products
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 10
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 11
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 12
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 13
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 14
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 15
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 16
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 17
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 18
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 19
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 20
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 21
Company Profile
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 22
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD.
Our Company mainly produce fence semi trailer, lowbed semi trailer , low fence semi trailer , rear dump semi trailer, container flat semi trailer, fuel oil semi trailer, etc all kinds of semi trailer, Our company have more than 20 years produce and exporting experience Quality is firstly, Credit is our base for business, Welcome to know us and build business relationship.
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 23
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 24
Factory :
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in
appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 25
Packing and Loading
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 26
Container usually us 45 feet
Usually by bulk
Certification
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 27

we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 28
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 29
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
High quality , factory lower price , good service !
120 T Payload 3 Axle 4 Axle Low Bed Trailer for Truck Heavy Duty Mechanical Equipment 30
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
