Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer

Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer

Large Image :  Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer

Product Details:
Place of Origin: SHANDONG CHINA
Brand Name: WOSHENG Rear Dump Semi Trailer
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $10,200.00/units 1-9 units
Payment Terms: T/T, L/C
Contact Now

Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 930*250*345M
Max Payload: >30000 Kg Product Name: Rear Dump Semi Trailer
Dimension: 9300*2500*3450mm(customizable) Tare Weight: 8500kg(depends On Final Configuration)
Max Loading Capacity: 60000kg(customizable) Floor Plate: Thickness 6mm
Sidewall: Thickness 4mm Axles: 16Ton. 3 Axles Brand Wosheng
Rim: 9.00-22.5 (optional) Landing Gear: 28t Heavy Duty Landing Gear. Brand FUWA
Color: As Per Customer Requirement

Products Description
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 0
Factory Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Dumper Trailer Rear Dump Semi Trailer
Wosheng Dump Semi Trailers are in great demand from customers, the proven product, which features reliable structure , great loading capacity, excellent power, reliable performance. This trailer model could meet the requirements of different road conditions, and could satisfy your need of long distance highway transportation.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 1
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 2
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 3
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 4
Specification
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 5
Wosheng Rear Dump Tipper Semi Trailer
Application
Transport all kinds of Mineral/Coal/Stone/Sand/Cargo Loading
Model
2 axles tipper trailer
3 axles tipper trailer
4 axles tipper trailer
5 - 6 axles tipper trailer
Bucket capacity
25 cubic meters
30/35/40 cubic meters
40 cubic meters
45 cubic meters
Dimension （mm）
8500*2500*3500
10000x2500x3800
10500*2500*3900
11500*2500*3950
Rim and tires
12.00R22.5 tires
9.0-22.5 rims
12.00R22.5 tires
9.0-22.5 rims
315/80R22.5 tires
9.0-22.5 rims
12.00R20 tires
9.0-20


Lifting system
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=202 mm
HYVA brand
FE/FC type cylinders
Diameter=214 mm
Tipping box
T700 / Hardox


Main Beams
T700 / Q345B double plate
Height:500mm
Upper Plate: 14mm
Middle Plate: 8mm
Lower Plate: 16mm
Axle
13T/16T FUWA / BPW Own Brand
King Pin
JOST brand 2.0'' / 3.5'' bolt type king pin
Landing Gear
28T double speed JOST / TAIHUA brand
Suspension
Heavy duty mechanical suspension / Air bag / Bogies
Pneumatic Braking System
WABCO RE 6 relay valve
T30/30 air brake chamber
Spring leaf
90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
(special for export market )
Light
LED light,24V,7ways(7 wire harness)

Tool Box
steel/aluminum

One piece,1m*0.5m*0.5m(Size can be choose freely)
Painting
1 coat of anticorrosive prime, 2coats of final paint
Any parts fitted could according to clients request, contact us to get more.
Details Images
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 6
Reinforcement side plate supporting design
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 7
Brake system
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 8
Tool box with enough important emergency tools
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 9
Spare Tire
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 10
Front axle lifting
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 11
Libricate counteraxle
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 12

Hydraulic and Power takeoff box, No need to install power output device on the engine


Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 13

Tail light guard


Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 14
Hydraulic dust cover
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 15
Double Coin / LingLong / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 16

Anti-Tire abrasion Suspension

Specially designed anti-Tire abrasion suspension system,Prevent tire offset after loading, maximally avoid tire
abrasion.Meanwhile,Easy to disassemble and maintain.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 17

Axle :BPW/FUWA/LEAO Axle optional.

Integrated Advanced Low-Alloy Axle Beam,Whole
Axle Beam No Welding process.Strong Carrying
Capacity and high bending Strength.Axle
maintenance-free could reach 3 Year/400,000
kilometers.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 18
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 19
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 20
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 21
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 22
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 23
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 24
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 25
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 26
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 27
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 28
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 29
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 30
Company Profile
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 31
About us
Qingdao Wosheng Import and Export Co., Ltd., is a company engaged in semi-trailer, truck, used semi-trailer, used-truck, auto parts and new energy vehicles’ sales and service. Our factory is Shandong Wosheng Special vehicle manufacturing co.,ltd , which has nearly 8 years of production experience in the trailer industry. Please believe that our professional technology and manufacturing experience can help your transportation be safer and efficient. we can provide high quality products and competitive prices.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 32
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 33
Factory
Our factory commit to strict quality
control and thoughtful customer
service, our experienced staff can
discuss your requirements at any time
to ensure your full satisfaction. We
not only want to be perfect in
appearance, but also pursue the
delicacy of detail. We have advanced
modern equipment, strong technical
force to ensure customer satisfaction
of products and timely delivery.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 34
Certifications
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 35
We have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 36
Why Choose Us
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 37
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility
model patents. We have attracted customers from all over the world, whether choosing the current
product from our catalog or seeking technical support for your application, you can talk to our
customer service colleagues about your procurement needs.
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 38
Packing and Loading
Direct Heavy Duty 3 Axles 4 Axles 50-80 Tons Hydraulic Tipper Rear Dump Semi Trailer 39
FAQ
Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.
Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements.
Such as: special Size, special control, or OEM/ODM etc.
Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.
Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF

Q6. What logistics ways we can work for shipment?
We can ship all trailer by various transportation tools
For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania etc, either by container or RoRo/Bulk Shipment.
For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
