Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport

Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport

Large Image :  Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport

Product Details:
Place of Origin: Shandong, China
Brand Name: WOSHENG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $9,000.00/units 1-9 units
Payment Terms: T/T, L/C
Contact Now

Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12400*2610*1550mm
Max Payload: 20T-80T Product Name: Flatbed Semi-trailer
Tare Weight: 20T-80T Axle: 4 Axle
Tire: 12R22.5 Suspension: Mechanical Suspension Air Suspension
King Pin: 2"(50mm) Or3.5"(90mm) Brake System: Dual Line Braking System

Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 0
Products picture
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 1
Wosheng Flatbed semi-trailers are usually used to transport 20FT/40FT/45FT container. The lower the center of gravity, the better the stability and safety, the better the ability to transport super high loads and pass overhead obstacles. According to the number of axles and the size of the tires, the load of the flatbed semi trailer is also different. The more the number of axles,the greater the load, and the load range is between 30-80 tons.
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 2
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 3
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 4
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 5
Products Description
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 6
Product Name
Flatbed Semi Trailer
Dimension(Lx W x H)（mm）
outside 12400×2610×1550mm (customizable)
Front Guard Height (mm)
1550mm (customizable)
Tare weight (kg)
7000 (depends on final configuration)
Max Loading Capacity (kg)
50000 （customizable)
Main Beam
Q345B / T700 Steel Height 500mm
upper plate is 14mm,
down plate is 16mm,
middle plate is 8mm. (customizable)
Side Beam
Q235 16# channel steel (customizable)
Bottom Plate
3mm diamond plate (customizable)
Axles
13/16/20 Ton. Axle amount optional like 2/3/4/6axles ..., Axle brand optional like SAF /FUWA/BPW etc
Tire
12.00R22.5/315 80R22.5/11.00R20/12.00R20(Brand optional)
Rim
9.00-22.5/8.00-20/8.50-20
King Pin
2"(50mm)or3.5"(90mm) JOST or other brand optional
Suspension
Mechanical Suspension Air Suspension(American or Geman)
Leaf Spring
90(w)mm*13/16(thickness)mm*10(layer)
Landing Gear
28t Heavy Duty Landing Gear. Brand optional FUWA/JOST etc.
Twist-lock
4/8/12 units (customizable)
Brake System
Dual line brake system, Air chamber T30/30,
3 X 40L gas storage drums
ABS System
None or installed as your requirement.
Electrical system
1. Voltage: 24v waterproof 2. Receptacle: 7 ways (7 wire harness); LED light ( standard rear light, turn light, rear reflector,
side light, side reflector etc.)
Color
As per customer requirement
Spare Wheel Bracket
1 piece of Spare Wheel Bracket
Tool box
1 set of standard tool box equipped with 1 Tire spanner, 1 gudgeon sleeve and 1 cranking bar
Products detail
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 7

Suspention - Anti-Tire Abrasion

avoids tires to the maximum extent worn out
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 8

bottom

stronger sturction
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 9

Axle

BPW/FUWA/LEAO Axle optional.Integrated advanced low-alloy axle beam,Whole axle beam no welding process.strong carrying capacity
and high bending strength.Axle maintenance-free could reach 3 year/400,000 kilometers.
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 10

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 11

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 12

Tire

use famous brand , or according to customer

Recommend Products
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 13
Company Profile
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 14
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 15
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 16
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD. Our company focuses on the development and production of semi-trailer, engaged in the semi-trailer industry has more than 20 years of rich experience, is a real set of trade and production as one of the manufacturers.our experienced staff can discuss your requirements at any time to ensure your full satisfaction. modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 17
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 18
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 19
Certification
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 20
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 21
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 22
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 23
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 24
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 25
We are your most reliable cooperation partner.
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 26
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 27
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 28
Exhibition
Max Payload 20T-80T 40 Ft 2 3 Axles Flatbed Semi-Trailer for Long-Distance Transport 29
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
