Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear

Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear

Large Image :  Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear

Product Details:
Place of Origin: Shandong, China
Brand Name: Yun Sheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $8,000.00/sets 1-3 sets
Payment Terms: T/T, L/C
Contact Now

Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel/stainless Steel Size: 9300x2500x3450mm Or Customization
Max Payload: >40000 Kg Axle: 3/4 Pcs
Suspension: Mechanical Or Air Suspension Landing Gear: 28T
Color: Customization Supply Ability: 15000 Sets Per Year

Products Description
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 0
Hydraulic Rear Dump Semi Trailer
***The frame chassis of this series adopts the through-beam structure, and the frame structure includes straight and gooseneck types. The overall strength is high, the weight is light, the appearance is beautiful, and the use is safe and reliable.
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 1

***The Dump Trailer is the main product of our company. It use high stength full thickness Steel, titanium content of 0.98‰, which ensure Beam and frame’s Toughness and strength. The strong Loading Capacity, 30-100 Tons Loading Range.
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 2

***The whole frame of the dump trailer should be shot blasted to effectively eliminate welding residues. The vehicle body iselectrophoretic coating, resistant to coating, and the coating effect can reach more than 10 years.
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 3

***We adopt world famous brand of parts, like JOST, braking valve etc. And the main part is Hydraulic support system. It is stable and long service life, we choose HYVA brand.
Specification
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 4
Wosheng Rear Dump Tipper Semi Trailer
Application
Transport all kinds of Mineral/Coal/Stone/Sand/Cargo Loading
Model
2 axles tipper trailer
3 axles tipper trailer
4 axles tipper trailer
5 - 6 axles tipper trailer
Bucket capacity
25 cubic meters
30/35/40 cubic meters
40 cubic meters
45 cubic meters
Dimension （mm）
8500*2500*3500
10000x2500x3800
10500*2500*3900
11500*2500*3950
Rim and tires
12.00R22.5 tires
9.0-22.5 rims
12.00R22.5 tires
9.0-22.5 rims
315/80R22.5 tires
9.0-22.5 rims
12.00R20 tires
9.0-20


Lifting system
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=191 mm
HYVA brand
FE/FC type cylinders
Diameter=202 mm
HYVA brand
FE/FC type cylinders
Diameter=214 mm
Tipping box
T700 / Hardox


Main Beams
T700 / Q345B double plate
Height:500mm
Upper Plate: 14mm
Middle Plate: 8mm
Lower Plate: 16mm
Axle
13T/16T FUWA / BPW / LEAO Own Brand
King Pin
JOST brand 2.0'' / 3.5'' bolt type king pin
Landing Gear
28T double speed JOST / TAIHUA brand
Suspension
Heavy duty mechanical suspension / Air bag / Bogies
Pneumatic Braking System
WABCO RE 6 relay valve
T30/30 air brake chamber
Spring leaf
90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
(special for export market )
Light
LED light,24V,7ways(7 wire harness)

Tool Box
steel/aluminum

One piece,1m*0.5m*0.5m(Size can be choose freely)
Painting
1 coat of anticorrosive prime, 2coats of final paint
Any parts fitted could according to clients request, contact us to get more.
Details Images
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 5
Reinforcement side plate supporting design
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 6
Brake system
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 7
Tool box with enough important emergency tools
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 8
Spare Tire
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 9
Front axle lifting
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 10
Libricate counteraxle
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 11

Hydraulic and Power takeoff box, No need to install power output device on the engine


Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 12

Tail light guard


Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 13
Hydraulic dust cover
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 14
Double Coin / LingLong / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 15

Anti-Tire abrasion Suspension

Specially designed anti-Tire abrasion suspension system,Prevent tire offset after loading, maximally avoid tire
abrasion.Meanwhile,Easy to disassemble and maintain.
Direct 3-6 Axles Tipping Tipper Rear Dump Truck Semi Trailer with 28T Landing Gear 16

Axle :BPW/FUWA/LEAO Axle optional.

Integrated Advanced Low-Alloy Axle Beam,Whole
Axle Beam No Welding process.Strong Carrying
Capacity and high bending Strength.Axle
maintenance-free could reach 3 Year/400,000
kilometers.
