12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer

12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer

Large Image :  12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer

Product Details:
Place of Origin: Shandong, China
Brand Name: YUN SHENG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2,800.00/units 1-1 units
Payment Terms: T/T, L/C
Contact Now

12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12400x2500x1550mm
Max Payload: 50 Ton Function: Transport 40ft Container
Main Beam: Q345B Height 500mm Upper/down/middle Plate Are 14mm /16mm/8mm Color: Customer's Request
Leaf Spring: 90(w)mm*13/16(thickness)mm*10(layer) Brake System: Dual Line Braking System
King Pin: 2"(50mm)or3.5"(90mm) JOST Axle: 13Ton, 3 Axles FUWA
Suspension: Mechanical Suspension Landing Gear: Heavy Duty Landing Gear 28t
Tire: 12.00R22.5/315 80R22.5/11.00R20(Brand Optional)

Products picture
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 0
Skeleton Semi Trailer.
Wosheng Skeleton Semi Trailer is an semi trailer with standardizes size (customization) and steel skeleton structure, mainly used for transporting container. This model have simple structure , strong durability, can adapt to complex transportation environment, and is an important part of modern logistics transportation. It is widely used in various types of international shipping ,railways road and other transportation occasions, can meet the transportation needs of different sizes and different shapes of containers.
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 1
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 2
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 3
Products Description
Product Name
Skeleton Semi Trailer
Dimension(Lx W x H)（mm）

Outside 12380×2480×1550mm (customizable)
Tare weight(kg)
6500 (depends on final configuration)
Max Loading Capacity (kg)
50000 （customizable)
Main Beam
Q345B / T700 Steel Height 500mm
upper plate is 14mm,
down plate is 16mm,
middle plate is 8mm. (customizable)
Axles
13/16/20 Ton. Axle amount optional like 2/3/4axles ..., Axle brand optional like SAF /FUWA/BPW etc
Tire
12.00R22.5/315 80R22.5/11.00R20/12.00R20(Brand optional)
Rim
9.00-22.5/8.00-20/8.50-20
King Pin
2"(50mm)or3.5"(90mm) JOST or other brand optional
Suspension
Mechanical Suspension Air Suspension(American or Geman)
Leaf Spring
90(w)mm*13/16(thickness)mm*10(layer)
Landing Gear
28t Heavy Duty Landing Gear. Brand optional FUWA/JOST etc.
Twist-lock
4/8/12 units (customizable)
Brake System
Dual line brake system, Air chamber T30/30,3 X 40L gas storage drums
ABS System
None or installed as your requirement.
Electrical system
1. Voltage: 24v waterproof 2. Receptacle: 7 ways (7 wire harness);
LED light ( standard rear light, turn light, rear reflector, side light,
side reflector etc.)
Color
As per customer requirement
Spare wheel bracket
1 piece of Spare Wheel Bracket
Tool box
1 set of standard tool box equipped with 1 Tire spanner, 1gudgeon sleeve and 1 cranking bar
Painting
Sand blasting before painting;one coats of primer, anti
corrosion; two coat of finish painting
Packing
Wax painting treatment to protect the vehicles from sea water,
and the chassis greased to avoid rusting during shipping.
Delivery
From China port, and carry by container ship, ro-ro ship or bulk
ship, the freight cost depends on the volume.
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 4
Products detail
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 5

Axle suspension and brake system

BPW Fuwa worldwide best axles worki with WABCO brake valve, More effectively brake for safe and save tire cost
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 6

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 7

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 8

Tire

use famous brand , or according to customer

12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 9
Company Profile
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 10
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 11
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 12
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD. Our company focuses on the development and production of semi-trailer, engaged in the semi-trailer industry has more than 20 years of rich experience, is a real set of trade and production as one of the manufacturers.our experienced staff can discuss your requirements at any time to ensure your full satisfaction. modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 13
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 14
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 15
Packing and Shipping
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 16
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 17
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 18
We are your most reliable cooperation partner.
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 19
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 20
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 21
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 22
Certification
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 23
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 24
Exhibition
12.00R22.5/315 80R22.5/11.00R20 optional Skeleton Semi Trailer for Container Truck Trailer 25
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
