car carrier trailers can be open or enclosed. Most commercial trailers have built-in ramps for loading
and off-loading cars, as well as power hydraulics to raise and lower ramps for stand-alone accessibility
|
Product Details:
|
| Use: | Truck Trailer, Tuck Trailer | Type: | Semi-Trailer |
|---|---|---|---|
| Material: | Steel | Size: | 16690x2700x3000 |
| Max Payload: | >30tons | Product Name: | 2 Axles Car Carrier Semi Trailer |
| Tire: | 11R22.5, 4pcs, Triangle Or And Other Brand | Rim: | 8.25x22.5 Steel Rim, 4 Pcs |
| Suspension: | 2-axles Enforced Mechanical Suspension | Landing Gear: | 1 Unit, Optioned By Factory |
| Kingpin: | 2" (50#) Or 3.5"(90#), Bolted Type | Brake System: | 30/30 Type On Two Axles, WABCO Brake Valve, With ABS |
Type | Car Carrier Trailer with Two Axles | ||
Dimension | Overall Dimension (mm) | Lengthx widthx height:16690x2700x3000 mm approx. | |
(The height will be adjusted according to the tractor specification) | |||
Kingpin Height (mm) | The height will be adjusted according to the tractor specification. | ||
Loading Height | The overall height when full loading based on the cars dimension. | ||
Configuration | Type | Two decks, top front deck and rear deck can be lifting and down separately by hydraulic system | |
Welding standard | All welding are to be done by qualified welder per applicable national standard | ||
Main beam | High tensile steel T700, beam height 300mm, top flange 12mm, middle web 8mm, bottom flange 12mm | ||
Stanchions | Reinforced design | ||
Tire | Type: 11R22.5, 4pcs, Triangle brand from China. | ||
Rim | 8.25x22.5 steel rim, 4 pcs | ||
Axle | ZY brand customized low center type for car carrier trailer, 13Tx 2 sets | ||
Suspension | 2-axles enforced mechanical suspension | ||
Landing Gear | 1 unit, optioned by factory | ||
Kingpin | 2”, bolted type | ||
Brake System | 30/30 type on two axles, WABCO brake valve, with ABS | ||
ABS | 4S/2M ABS | ||
Electrical System | 24V, LED lamp | ||
Spare Tire Carrier | Equip 1 set per chassis | ||
Tool Box | 1 set | ||
Hydraulic System | High quality hydraulic system, power taken off truck head. | ||
(PTO device provide by the client according to the truck head brand. ) | |||
Accessories | Tighten device 16pcs each deck, include tighten tape. | ||
8kg, 2pcs, fire Extinguisher | |||
Painting | All steel shall be sandblasted to SA 2.5 and painted Epoxy zinc phosphate primer and polyurethane finish painting (anti-corrosion), with client Logo. Specification for the Logo provided by the client. | ||
Color | By customer requirement. | ||
Pre-shipping treatment | Wax painting treatment to protect the vehicles from sea water, and the chassis greased to avoid rusting during shipping. | ||
