Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport

Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport

Large Image :  Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport

Product Details:
Place of Origin: SHANDONG CHINA
Brand Name: WO SHENG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $13,800.00/units 1-4 units
Payment Terms: T/T, L/C
Contact Now

Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 16690x2700x3000mm
Max Payload: >30000 Kg Function: Car Carrier Semi Trailer
Color: Customer's Request Landing Gear: 1 Unit, Optioned By Factory
King Pin: 2" (50#), Bolted Type Suspension: 2-axles Enforced Mechanical Suspension
Rim: 8.25x22.5 Steel Rim, 4 Pcs Tire: 11R22.5, 4pcs, Triangle Or And Other Brand

Products Description
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 0
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 1
Car Carrier Semi Trailer
WO SHENG Car carrier Trailer is designed to efficiently transport passenger vehicles via truck. Modern car carrier trailers can be open or enclosed. Most commercial trailers have built-in ramps for loading and off-loading cars, as well as power hydraulics to raise and lower ramps for stand-alone accessibility
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 2
Specification
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 3
Overall Dimension (mm)
Length width height:16690x2700x3000 mm approx.
(The height will be adjusted according to the tractor specification)
Kingpin Height (mm)
The height will be adjusted according to the tractor specification.
Loading Height
The overall height when full loading based on the cars dimension.
Type
Two decks, top front deck and rear deck can be lifting and down separately by hydraulic system
Welding standard
All welding are to be done by qualified welder per applicable national standard
Main beam
High tensile steel T700, beam height 300mm, top flange 12mm, middle web 8mm, bottom flange 12mm
Stanchions
Reinforced design
Tire
Type: 11R22.5, 4pcs, Triangle brand from China.
Rim
8.25x22.5 steel rim, 4 pcs
Axle
brand customized low center type for car carrier trailer, 13Tx 2 sets
Suspension
2-axles enforced mechanical suspension
Landing Gear
1 unit, optioned by factory
Kingpin
2“（50#）
Brake System
30/30 type on two axles, WABCO brake valve, with ABS
ABS
4S/2M ABS
Electrical System
24V, LED lamp
Spare Tire Carrier
Equip 1 set per chassis
Tool Box
1 set
Hydraulic System
High quality hydraulic system, power taken off truck head.
(PTO device provide by the client according to the truck head brand. )
Accessories
Tighten device 16pcs each deck, include tighten tape.
8kg, 2pcs, fire Extinguisher
Painting
All steel shall be sandblasted to SA 2.5 and painted Epoxy zinc phosphate primer and polyurethane finish painting
(anti-corrosion), with client Logo. Specification for the Logo provided by the client.
Color
By customer requirement.
Pre-shipping treatment
Wax painting treatment to protect the vehicles from sea water, and the chassis greased to avoid rusting during shipping.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 4

Axle

BPW/FUWA/LEAO Axle optional.Integrated advanced low-alloy axle beam,Whole axle beam no welding process.strong carrying capacity and high bending strength.Axle maintenance-free could reach 3 year/400,000 kilometers.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 5

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 6

Suspension and break system

Suspension: Germany Type or American Type Mechanical and Air bag suspension can be choose. Brake System: T30/30 Spring brakechamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 7

Tire

Double Coin / Ling Long / Michelin / Triangle / Bridgestone and other famous brand for choice. Better Performance in wear resistance.
Company Profile
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 8

About us

Qingdao Wosheng Import and Export Co., Ltd., is a company engaged in semi-trailer, truck, used semi-trailer, used-truck, auto parts and new energy vehicles’ sales and service. Our factory is Shandong Wosheng Special vehicle manufacturing co.,ltd , which has nearly 8 years of production experience in the trailer industry. Please believe that our professional technology and manufacturing experience can help your transportation be safer and efficient. we can provide high quality products and competitive prices.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 9
Factory
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 10
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 11
Certifications
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 12
We have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 13
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 14
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 15
Packing and Loading
Max Payload 30000 kg Steel Overland Double Deck Semi Trailers for Car Hauler Transport 16
FAQ
Q1. Are you a factory or trade company ?
We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time. Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc. Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion. Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality. Q5. What services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF Q6. What logistics ways we can work for shipment? We can ship all trailer by various transportation tools. For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania etc, either by container or RoRo/Bulk Shipment. For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, or Fedex.
