Product Details:
|
| Use: | Truck Trailer | Type: | Semi-Trailer |
|---|---|---|---|
| Material: | Steel | Size: | 15100mmx2550mmx4000mm |
| Max Payload: | 40tons | Product Name: | Open Wing Catgo Van Semi Trailer |
| Function: | Like LOGISTIC CARGO TRANSPOTATION | Axle: | 13T 16T BPW/FUWA |
| Color: | Customer's Request | Suspension System: | Mechanical /Air Suspension |
| King Pin: | 90#(3.5") JOST/Other Brand | Tire: | 12R22.5 12units |
| Rim: | 9.00-22.5 | Brake System: | Dual Line Brake System WABCO |
Product Name | Double Wing Semi Trailer |
Color | According to customer demands. |
Tare weight | 7.5tons |
Tire | 12R22.5 12units (brand optional) |
Loading capacity | 50tons |
Axle | WS/BPW/FUWA ,13T 16T, American/ German axle |
Main beam | Q345B Steel upper plate is 14mm middle plate is 8mm down plate is 16mm |
Side beam | 4mm thickness, |
Open manner | double back door and the top can be expanded |
Base Plate | 3mm |
King pin | 90#(3.5") 12units |
Tire | 12R22.5 12units （Brand optional) |
Suspension | Mechanical/Air suspension system |
Brake System | wabco relay valve，t30/30 brake chamber |
Light | LED |
Landing Gear | 28 Ton JOST/Other Brand |
Rim | 9.00-22.5 |
ABS | Optional |
Electrical system | 24V 7 ways |
Spare tire carrier | 1 pieces |
Accessories | 1. one standard box |
2. with a set of standard trailer tools |
