3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar

3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar

Large Image :  3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar

Product Details:
Place of Origin: SHANDONG, Shandong, China
Brand Name: YUN SHENG
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $14,000.00/units 1-1 units
Payment Terms: T/T, L/C
Contact Now

3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel/Aluminum / Alloy, Steel/Aluminum / Alloy Size: 10500/11000/12000mm*2490mm*3990mm, 10500/11000/12000mm*2490mm*3990mm
Max Payload: 60Ton Usage: Truck Trailer
Payload: 30t/40t/50t/60t80t(30-70cbm) Discharging Pipe: 3 Or 4 Inch Rubber Hose , 7m Standard
Air Compressor: Bohai 12-15 M3 Double Cylinder Optional Working Press: 2.5 Bar
King Pin: JOST 2" Or 3.5 " Bolting Type

3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 0
Shandong Wosheng Semi Trailers
Qingdao Wosheng Import and Export Co., Ltd is a professional semi-trailer manufacturer with more than ten years of production experience. With a professional R & D team, we can according to your needs specializing in the production of customized high quality trailer. We provide the best quality, factory price, timely delivery and perfect after-sales. Please contact us if necessary.
Product Description
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 1

1. The bulk cement semi-trailer uses the engine power to drive the on-board air compressor through the power take-off, sends the compressed air into the tank, and liquefies the powdery material through the liquefaction device. Due to the pressure difference between the inside and outside of the tank, the powdery material is transported to the designated position along the discharge line along with the air.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 2

2. External Weichai 4100 engine and Wuhu 10.00 vehicle air compressor unit ensure sufficient air pressure when the vehicle is unloading, and the exhaust speed can reach 1.6 tons per minute.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 3

3. It is manufactured by domestic advanced technology, with novel design, strong and durable. The air bag type has large bearing capacity, fast unloading speed and small margin.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 4

4. The Wosheng integrated tanker has the characteristics of high overall strength, good rigidity, good pressure bearing and good performance.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 5

5. It has reasonable design, short discharge time, and discharge speed of 1.2-1.6 tons/minute, which improves the volumeutilization rate of the tank and reduces the residual ash rate by 0.2%.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 6

***The main volume of the Wosheng bulk cement trailer is 25/30/35/40/55/65 cubic meters. This trailer can load bulk cement, grain, sodium bicarbonate and any bulk powdered material. Loading capacity from 40 tons to 80 tons, V (banana) type, W type and dump type for your choice. Available in carbon steel, stainless steel and aluminum alloys, we also support custom designs, which help to getthe most suitable vehicle.
***Our Advantage:
1. Full load rate>98%
2. Residual rate <0.3%
3. Conveying height>15m suitable for most silos
4. Faster discharge >1.5ton/min to save fuel
Specification
Specification for Wosheng Bulk Cement Semi Trailer
Bulker Body
Shape
V type or W type
Dimension
10500/11000/12000mm*2490mm*3990mm ( Exact size depends on the final design)
Payload
28T - 125tons
Volume
25cbm - 100cbm
Material
Carbon Steel/ Aluminum/ Stainless Steel
Tare weight
About 7500KGS-15000KGS
Compartments
1-3
Tanker body
6mm
Manhole Cover
3 - 5 pcs
Carbon steel or Aluminum500mm
Air Compressor
Bohai 12 - 15 m3 double-cylinder or other brand
Diesel Engine
Deutz or Huafeng engine/Weichai/Tianhe 4102 4100 or other brand
Discharge Valve
3 or 4 inch disc valve (Material: Aluminum )
Discharging Pipe
3 or 4 inch rubber hose, 1pcs, 6m/each
Spry cooling system
2 Pcs Water tankers Pneumatic Power
Chassis
Main Beam
Q345 Carbon steel material
Tanker Body and End Plate
5mm or 6mm/ Q235 carbon steel
Axles
2 - 3 pcs 13 - 20tons BPW or Fuwa Axles
Suspenssion
Mechanical suspension/Germany or America type /Air Suspension
Leaf Spring
90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
Landing Leg
JOST E100 or A400 Heavy duty type
Brake system
6pcs T30/30 Brake Chambers, WABCO relay valve
Tire
12 pcs 12R22.5 or 315/80R22.5 or 12.00R24 Triangle Brand
Rim
9.00-22.5/8.00-20/8.5-20 China Brand
King Pin
JOST 2" or 3.5 " Bolting Type
Painting
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Any parts fitted could according to clients request, contact us to get more.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 7
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 8
Details Images
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 9
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 10
Recommend Products
Company Profile
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 11
Shandong Wosheng Special Vehicle Manufacture Co., LTD ,
Sub-Qingdao Wosheng Import and Export Co., ltd
has more than 15 years of production experience in the trailer industry. Please believe that our professional technology and manufacturing experience can help your transportation be safer and more efficient. We can provide high quality products and competitive prices. Please contact me if necessary.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 12
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 13
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 14
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 15
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 16
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 17
Certifications
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 18
Why Choose Us

We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 19
3 Axle 45 50 60 cbm Fly Ash Silo Cement Tanker Trailer with Working Press of 2.5 Bar 20
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.
Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.
Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.
Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.
Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
Q6. What logistics ways we can work for shipment?
We can ship all trailer by various transportation tools
For 90% of our shipment, we will go by sea, to all main continents such as South America, Middle East,
Africa, Oceania etc, either by container or RoRo/Bulk Shipment.
For neighborhood countries of China, such as Russia, Tajikistan, Kazakhstan,Mongolia etc, we can
ship trucks by road or railway. For light spare parts in urgent demand, we can ship it by international
courier service, such as DHL, TNT, UPS, or Fedex.
