Product Details:
|
| Condition: | Used, Used | Steering: | Left |
|---|---|---|---|
| Horsepower: | 351 - 450hp, 480hp | Emission Standard: | Euro 2/3/4/5/6 |
| Make: | Howo, Howo | Segement: | Heavy Truck, Heavy Truck |
| Market Segement: | Urban Construction Muck Transportation | Fuel Type: | Diesel |
| Engine Capacity: | 4 - 6L, >8L | Cylinders: | 6 |
| Transmission Type: | Manual | Forward Shift Number: | 5, 16 |
| Reverse Shift Number: | 2 | Maximum Torque(Nm): | 2000-2500Nm |
| Cargo Tank Dimension: | 5400x2300x1400 | Cargo Tank Length: | 5.3-6.2M |
| Gross Vehicle Weight: | 10-15T, 20000 Kg | Fuel Tank Capacity: | 400-500L |
| Drive Wheel: | 6x4 | Passengers: | 3 |
| Driver's Seat: | Normal | Rear Camera: | 360° |
| ABS(Antilock Braking System): | Yes | ESC(Electronic Stability Control System): | Yes |
| Touch Screen: | None | Multimedia System: | Yes |
| Window: | Manual | Air Conditioner: | Manual |
| After-sales Service Provided: | Onsite Installation, Video Technical Support, Overseas Call Centers, Return And Replacement, Online Support | Color: | Customer's Request |
Detail Specification | ||
Items | Dump truck | |
Dimension (mm) | 8685x2496x3850mm | |
Overhang(front/rear) (mm) | 1500x725mm | |
Wheel Base (mm) | 3625+1350 | |
Engine | 13280X2440X2547mm （customization) | |
Modle | WP 12.400E201 | |
Emission | EURO II | |
Displacement（L) | 11.896 | |
Power | 400hp/295kw.2000r/min | |
Type | Water-cooled, four strokes, 6 cylinders in line, turbocharged directly injection | |
Fuel Consumption(l/100km) | 25L/100km | |
Axles | Mechanical suspension air suspension (American or Geman) | |
Front Axle Model | VGD95 axle, Capacity: 9000kg | |
Rear Axle | HC16 axle. Capacity:2X 16000KG | |
Ratio of rear axle | 4.8 | |
Electrical System | 9.00-22.5 /8.00-20/8.5-20 | |
Battery | 2x12V/165Ah | |
Alternator | 28V-1500kw | |
Starter | 7.5Kw/24V | |
Brake System | 24 volt electrical system 7 pin electrical connector, Parking stop, reverse, number plate and indicator lights, rear lights conform to european standard, rear front and side reflectors | |
Service brake | Dual circuit compressed air brake | |
Parking brake | Spring energy, compressed air operating on rear wheels | |
Auxiliary brake | Engine exhaust brake | |
Steering System | From China Port and carry by container ship, ro-ro ship or by bulk | |
Modle | ZF8118 | |
Type | Hydraulic steering with power assistance | |
