Product Details:
|
| Use: | Truck Trailer | Type: | Semi-Trailer |
|---|---|---|---|
| Material: | Aluminum / Alloy, Aluminum Alloy | Size: | 13000*2550*3780mm |
| Max Payload: | 60Ton | Product Name: | Oil Tank Semi-trailer |
| Usage: | Transport Fuel Oil | Axle: | Standard Axle |
| Suspension: | Mechanical Suspension | Color: | Customized Color |
| Landing Gear: | Standard 28 Ton | Tire: | 12R22.5 |
| King Pin: | 2"(50mm)or3.5"(90mm) JOST |
Material | Carbon Steel/Aluminum/Stainless Steel | ||||
Application | Fuel/Liquid Loading | ||||
Volume of Tank | 20-55 CBM Customized | ||||
Axle | 2/3/4 Axles | ||||
Compartment | 1 to 9 | ||||
Length*Width*Height | 13000mm*2500mm*3800mm | ||||
European System | Available | ||||
Thermal | Available | ||||
Manhole | Anti-Explosion | ||||
Lifted Axle | Available | ||||
Vehicle Examination | X-RAY Room Examination | ||||
OEM/ODM | Available | ||||
SKD/CKD Cooperation | Available | ||||
Tank Shape | D Style/Round Style | ||||
Item | Spec. | ||||
Tank Thickness | 5mm | ||||
Dish End Thickness | 6mm | ||||
Buffle Thickness | 4mm | ||||
The spare parts below are based on the quantity of compartments.For ExampleOne Compartment. | |||||
Manhole | X-RAY Room Examination | ||||
Discharge Valve | 2*3 inch | ||||
Bottom Valve | 4 inch Aluminum | ||||
Discharge Pipe | 3 inch rubber hose,6m/each | ||||
Hose Carrier | 2 Pieces Carbon Steel/Aluminum | ||||
Axles | 2/3/4 Axles *13/16 Ton FUWA/BPW/Other | ||||
Tire | 12R22.5/11.00r20 (8/12/16 Pieces) Linglong/Triangle/Double-Coin/Bridgestone/Other | ||||
Rim | 9.00*22.5/8.0 (8/12/16 Pieces) Steel/Aluminum | ||||
Leaf Spring | 90mm*13mm*10/90mm*16mm*10 | ||||
Suspension System | Mechanical or Air Suspension | ||||
Kin Pin | 50#(2")/90#(3.5") JOST/Other Brand,Changeable | ||||
Landing Gear | 28 Tons Two Speed,/JOST/Other Brand | ||||
Tool Box | Steel or Aluminum | ||||
Extinguisher | 2 Sets | ||||
Above Information are Standard Spec.If customer want to change Spec.Please Let us know. Want to know more details,please contact us directly. | |||||
