3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload

3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload

Large Image :  3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload

Product Details:
Place of Origin: Shandong China
Brand Name: Yun Sheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $7,600.00/units 1-3 units
Payment Terms: T/T, L/C
Contact Now

3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12500x2500x1600-3100mm Or Customizable
Max Payload: 50tons Function: Transport 20ft 40ft Container
Main Beam: Q345B, Height 0.5m, Upper /down/middle Plate Is 14/16/8mm Color: Customized Color
Leaf Spring: 90(w)mm*13/16(thickness)mm*10(layer) King Pin: 2"(50mm)or3.5"(90mm)
Axle: 13ton*3 Axles Suspension: Mechanical Suspension
Landing Gear: 28t Heavy Duty Landing Gear Tire: 12.00R22.5

Products picture
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 0
Flatbed Semi Trailer.
Wosheng Flatbed semi-trailers are usually used to transport 20FT/40FT/45FT container The lower the center of gravity, the better the stability and safety, the better the ability to transport super high loads and pass overhead obstacles. According to the number of axles and the size of the tires, the load of the flatbed semi trailer is also different. The more the number of axles,the greater the load, and the load range is between 30-80 tons.
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 1
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 2
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 3
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 4
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 5
Products Description
Product Name
Flatbed Semi Trailer
Dimension(Lx W x H)（mm）
outside 12400×2610×1550mm (customizable)
Front Guard Height (mm)
1550mm (customizable)
Tare weight (kg)
7000 (depends on final configuration)
Max Loading Capacity (kg)
50000 （customizable)
Main Beam
Q345B / T700 Steel Height 500mm
upper plate is 14mm,
down plate is 16mm,
middle plate is 8mm. (customizable)
Side Beam
Q235 16# channel steel (customizable)
Bottom Plate
3mm diamond plate (customizable)
Axles
13/16/20 Ton. Axle amount optional like 2/3/4/6axles ..., Axle brand optional like SAF /FUWA/BPW etc
Tire
12.00R22.5/315 80R22.5/11.00R20/12.00R20(Brand optional)
Rim
9.00-22.5/8.00-20/8.50-20
King Pin
2"(50mm)or3.5"(90mm) JOST or other brand optional
Suspension
Mechanical Suspension Air Suspension(American or Geman)
Leaf Spring
90(w)mm*13/16(thickness)mm*10(layer)
Landing Gear
28t Heavy Duty Landing Gear. Brand optional FUWA/JOST etc.
Twist-lock
4/8/12 units (customizable)
Brake System
Dual line brake system, Air chamber T30/30,
3 X 40L gas storage drums
ABS System
None or installed as your requirement.
Electrical system
1. Voltage: 24v waterproof 2. Receptacle: 7 ways (7 wire harness); LED light ( standard rear light, turn light, rear reflector,
side light, side reflector etc.)
Color
As per customer requirement
Spare Wheel Bracket
1 piece of Spare Wheel Bracket
Tool box
1 set of standard tool box equipped with 1 Tire spanner, 1 gudgeon sleeve and 1 cranking bar
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 6
Products detail
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 7

Suspention - Anti-Tire Abrasion

avoids tires to the maximum extent worn out
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 8

bottom

stronger sturction
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 9

Axle

BPW/FUWA/LEAO Axle optional.Integrated advanced low-alloy axle beam,Whole axle beam no welding process.strong carrying capacity and high bending strength.Axle maintenance-free could reach 3 year/400,000 kilometers.
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 10

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 11

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 12

Tire

use famous brand , or according to customer

Recommend Products
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 13
Company Profile
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 14
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 15
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 16
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD. Our company focuses on the development and production of semi-trailer, engaged in the semi-trailer industry has more than 20 years of rich experience, is a real set of trade and production as one of the manufacturers.our experienced staff can discuss your requirements at any time to ensure your full satisfaction. modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 17
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 18
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 19
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 20
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 21
We are your most reliable cooperation partner.
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 22
Certification
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 23
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 24
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 25
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 26
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 27
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 28
Exhibition
3 or 4axle Ship Cargo and 20ft 40ft Container Flatbed Trailer with 50tons Max Payload 29
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
